FIC A440 (Gericom 1st Supersonic MSW)

CPU

Sockel 370, PGA, Intel nonmobile P3, kein Tualatin

Chipsatz

VIA PLE 133, bis 133 MHz FSB

VGA

Trident Cyberblade Ai1 AGP, 2, 4 oder 8 MB shared Ram

Ram

max. 2 x 256 MB SO-SDRAM, PC 100 oder PC 133 (16 Chips)

Sound

VIA, Vinyl AC97

Touchpad

Alps

Harddisk

max. 128 GB, 2,5 Zoll IDE (40-Pin)

Slimline

CD, CDRW, DVD, DVDRW, IDE, nur Master (1)

(1) Master durch Firmwareupdate des Laufwerks oder Lötverbindung zwischen Pin 45 und 47

Treiber:

Windows 98
Windows NT 4
Windows 2000
Windows XP
PHDISK

Handbücher:

Benutzerhandbuch
Servicehandbuch

Jumper:

S4
core/bus frequency ratio

Pos#4

Pos#3

Pos#2

Pos#1

CPU

PCI

off

off

off

off

91,5

30,5

off

off

off

on

66,82

33,41

off

off

on

off

96,22

32,07

off

off

on

on

90

30

off

on

on

off

133,33

33,33

off

on

off

on

83,1

27,77

off

on

on

off

95

31.67

off

on

on

on

100

33.3

on

off

off

off

75

37,5

on

off

off

on

137

34,25

on

off

on

off

83,31

41,65

on

off

on

on

105

35

on

on

off

off

109,99

36,66

on

on

off

on

114,99

38.33

on

on

on

off

120

40

on

on

on

on

124

41,33



S3
POS#1 on/off = GPI6PUSET TBD

keyboard type

Pos#2

Pos#3

type

off

off

US

off

on

JP

on

off

GR

on

on

reserved


Pos#4 on = Clear CMOS

S1
CPU core voltage setting

Vcore

Pos#4

Pos#3

Pos#2

Pos#1

2,4

on

on

on

on

2,2

off

on

on

on

2,0

on

off

on

on

1,9

on

on

off

on

1,8

on

on

on

off



BIOS:

BIOS Version H
BIOS Version I
